Passthrough mount of a Nintendo Switch nand dump on linux

Introduction

This is a short post I’m doing as a way to fix this knowledge somewhere, because I’ve found myself having to reinvent the wheel every time I’ve wanted to do this.
Nintendo Switch dumps tend to be quite heavy and unwieldy, so it sucks when you want to extract a single file from them and have to first unpeel several layers of partitioning, while extracting huge files over and over.

By chaining a few tools and utilities, you can achieve a passthrough mount from the raw nand dump, to the actual filesystem.

Setup

1. Clone and compile busehac. Use make RELEASE=1 -j$(nproc)I’ve hit some kind of obscure bug last time, where mbedtls global state was somehow corrupted on executable load. This might’ve been because the mbedcrypto library was compiled in release mode, while the tool was compiled in debug mode. If busehac stops responding on launch, make sure to compile on release mode.
   You can also add -DRELEASE to the CFLAGS in the Make script to remove the noisy debug logging.
2. Enable network block devices: sudo modprobe nbd.
3. Find out the partition layout: fdisk -l rawnand.bin. Verify the sector size, which should be 0x200 bytes. Note the partition start and size (I’ll refer to those as pstart and psize).
   You can correlate with the info on switchbrew.
4. Setup a loop device over the partition: sudo losetup -f --show --offset $((0x200*pstart)) --sizelimit $((0x200*psize)) rawnand.bin. This will output a loop device node, loopnode.
5. Launch busehac: sudo busehac --keyfile keys.txt N loopnode /dev/nbd0, where N is the bis key number (see switchbrew for mapping). The keys file should contain the BIS keys for this nand dump.
6. Finally, mount the decrypted partition: sudo mount -o ro /dev/nbd0 mount.Make sure to mount as read-only. I wouldn’t trust busehac for writes.

You can also read the decrypted partition data directly:This is useful if you want to extract the decrypted Prodinfo.

$ sudo dd if=/dev/nbd0 bs=$((0x100)) count=1 status=none | xxd
00000000: ebe9 9000 0000 0000 0000 0000 0220 2000  .............  .
00000010: 0200 0000 00f8 0000 3f00 1000 0000 0000  ........?.......
00000020: 0000 e006 006e 0000 0000 0000 0200 0000  .....n..........
00000030: 0100 0600 0000 0000 0000 0000 0000 0000  ................
00000040: 8001 2900 0000 004e 4f20 4e41 4d45 2020  ..)....NO NAME
00000050: 2020 4641 5433 3220 2020 0000 0000 0000    FAT32   ......
00000060: 0000 0000 0000 0000 0000 0000 0000 0000  ................
00000070: 0000 0000 0000 0000 0000 0000 0000 0000  ................
00000080: 0000 0000 0000 0000 0000 0000 0000 0000  ................
00000090: 0000 0000 0000 0000 0000 0000 0000 0000  ................
000000a0: 0000 0000 0000 0000 0000 0000 0000 0000  ................
000000b0: 0000 0000 0000 0000 0000 0000 0000 0000  ................
000000c0: 0000 0000 0000 0000 0000 0000 0000 0000  ................
000000d0: 0000 0000 0000 0000 0000 0000 0000 0000  ................
000000e0: 0000 0000 0000 0000 0000 0000 0000 0000  ................
000000f0: 0000 0000 0000 0000 0000 0000 0000 0000  ................

Teardown

1. Unmount the partition: sudo umount mount.
2. Stop busehac.
3. Destroy the loop device: sudo losetup -d loopnode.

Addendum: Flashing another console’s Prodinfo

This describes the steps required to boot a console using a donor Prodinfo, which can be used to temporarily unban a unit.

• Dump the decrypted Prodinfo using the method outlined above.
• Flash it using TegraExplorer or a similar tool (back up your original Prodinfo first). Place the file on your SD card, named PRODINFO (no extension), navigate to it, copy it to the clipboard, navigate to the eMMC/emuMMC filesystem, and flash the clipboard contents.You might get a warning that the flashed file is smaller than the partition, you can ignore it.
• Find the device id in the donor Prodinfo. It is a 16-bytes ASCII string, found at offset 0xc6 within the console-unique EccB233DeviceCertificate,Some consoles (OLED models in particular) have been observed to use Rsa2048DeviceCertificate instead, at offset 0x3d70. If the EccB233 one is cleared, check this location instead. which itself is at offset 0x480.See switchbrew here and there. The format is NX0011223344556677-X, what you want is the 0..7 string.
• Patch exosphère (Atmosphère’s secure monitor reimplementation) to hardcode the device id.Normally the device id is derived from fused, device-unique data related to the SoC chip fabrication (wafer fab, lot, X/Y position, etc). Add an early return to the GetDeviceId function, to yield the number found above, without the leading byte (ie. return 0x11223344556677ull;).
• Instruct hekate to load your custom exosphère binary, by adding secmon=path/to/exosphere.bin, after the fss0/pkg3 line, to your hekate_ipl.ini.
